Features
Impressive size
Modest footprint of just 100-in (254-cm) transport width and 26-ft (7.9-m) length makes it right for a range of installation specifications — even in congested urban jobsites.
Increased power
Up to 60,000 lb (226.9 kN) of thrust and pullback and 9250 ft-lb (12,202.4 Nm) of rotational torque helps you get the job done faster.
Significantly quieter
Guaranteed sound power rating of just 107 dB(A) – 12 dB(A) lower than its predecessor the D60x90 – resulting in reduced noise at operator’s ear [83 dB(A)], increased operator comfort and less noise disturbance in residential or urban areas.
DigiTrak® Aurora® touchscreen display
New interactive, full-color DigiTrak® Aurora® touchscreen display allows operators to load the bore plan via flash drive and view it on screen — eliminating hard copy plans.
Large open-top vise
Large open-top vise design allows passage of larger tooling for ease of tool removal and installation.
Convenient rod loading
Popular and proven rod loader design provides easy and reliable performance.
Specs
| General Dimensions and Weights | |
| Length (Minimum Transport) | 354 in |
| Width (Minimum Transport) | 90 in |
| Height (Minimum Transport) | 104 in |
| Height (With Cab) | 104 in |
| Weight | 42150 lbs |
| Angle of Approach | 18 deg |
| ENGINE | |
| Make and Model | Cat |
| Fuel Type | Ultra Low Sulfur Diesel |
| Maximum Engine RPM | 2200 rpm |
| Gross Horsepower | 202 hp |
| Aspiration | Turbo Charged |
| OPERATIONAL | |
| Thrust | 60000 lbs |
| Pullback | 60000 lbs |
| Maximum Carriage Speed at Maximum Engine RPM | 175 ft/min |
| Maximum Carriage Speed in Low at Maximum Engine RPM | 55 ft/min |
| Maximum Spindle Torque (Low at Maximum Engine RPM) | 9250 ft-lb |
| Maximum Spindle Torque (Medium at Maximum Engine RPM) | 6810 ft-lb |
| Maximum Spindle Torque (High at Maximum Engine RPM) | 3790 ft-lb |
| Maximum Spindle Speed at Max Engine RPM | 200 rpm |
| Minimum Bore Diameter | 6 in |
| Maximum Ground Drive Speed at Maximum Engine RPM | 3.7 mph |
| Automated Rod Loader | Yes |
| Noise Level at Operator's Ear | 83 dB(A) |
| FLUID CAPACITIES | |
| Fuel Tank | 90 gal |
| Hydraulic Tank | 75 gal |
| Hydraulic System | 100 gal |
| HYDRAULIC SYSTEM | |
| Auxiliary Pump Flow at Maximum Engine RPM | 13.4 gpm |
| Auxiliary Pump Relief Pressure | 3000 psi |
| Thrust/Pullback Pump Flow at Max Engine RPM | 41 gpm |
| Thrust/Pullback Pump Relief Pressure | 5500 psi |
| Rotation Pump Flow at Maximum Engine RPM | 55 gpm |
| Rotation Pump Relief Pressure | 5800 psi |
| DRILLING FLUID SYSTEM OPTION ONE | |
| Maximum Flow | 150 gpm |
| Maximum Pressure | 900 psi |
| Brand | Kerr |
| FEATURES | |
| Breakout System | Open top Vise |
| Drilling Lights | Standard |
| Flow Indicator | Standard |
| Stakedown System | Two Options |
| Cab | Standard |
| Strike Alert | Standard |
| Remote Lockout | Standard |
| Operator Presence | Standard |
