Features
PREMIUM PERFORMANCE
40,000 lb (177.9 kN) of thrust/pullback and 5500 ft-lb (7457 Nm) of rotational torque help operators get the job done faster.
RANGE OF ROD OPTIONS
Available with a range of 10-ft or 15-ft (3-m or 4.6-m) rod options — so it can be configured to the specific needs of a contractor.
CLASS-LEADING CYCLE TIMES
Carriage speeds of 188 fpm (57.3 m/min) helps contractors install more linear feet per day.
SIGNIFICANT SOUND REDUCTION
A 104 dB(A) guaranteed sound power level and an operator ear rating of 82.9 dB(A) makes it one of the quieter drills on the market — contributing to less neighborhood disturbance.
COMFORTABLE CAB
The excavator-style cab provides operators greater comfort with more legroom.
AURORA TOUCHSCREEN DISPLAY
Interactive full-color, touchscreen display from Aurora® delivers real-time, easy-to-view locate information, bore plans and more.
Specs
| General Dimensions and Weights | |
| Length (Minimum Transport) | 241 in 612.1 cm |
| Width (Minimum Transport) | 89 in 226.1 cm |
| Width (With Cab, Minimum Transport) | 89 in 226.1 cm |
| Height (Minimum Transport) | 76 in 193 cm |
| Height (With Cab) | 92 in 233.7 cm |
| Weight | 22380 lbs 10151.4 kg |
| Weight (Cab Option) | 26110 lbs 11843.3 kg |
| Angle of Approach | 18 deg |
| Engine | |
| Make and Model | John Deere 4045 |
| Fuel Type | Ultra low sulfur diesel |
| Maximum Engine RPM | 2400 rpm |
| Gross Horsepower | 140 hp 104.4 kw |
| Aspiration | Turbo |
| Max Fuel Consumption | 7.4 gph 28 lph |
| Maximum Operating Angle (Fore/Aft)* | 30 |
| Maximum Operating Angle (Left/Right)* | 25/25 |
| Engine Option Two | |
| Make and Model | John Deere 4045 |
| Fuel Type | Diesel |
| Maximum Engine RPM | 2400 rpm |
| Gross Horsepower | 140 hp 104.4 kw |
| Aspiration | Turbo |
| Max Fuel Consumption | 7.4 gph 28 lph |
| Maximum Operating Angle (Left/Right)* | 30 deg |
| Operational | |
| Thrust | 40000 lbs 177.9 kN |
| Pullback | 40000 lbs 177.9 kN |
| Maximum Carriage Speed at Maximum Engine RPM | 188 ft/min 57.3 m/min |
| Maximum Carriage Speed in Low at Maximum Engine RPM | 75 ft/min 22.9 m/min |
| Maximum Spindle Torque (Low at Maximum Engine RPM) | 5500 ft-lb 7457 Nm |
| Maximum Spindle Torque (Medium at Maximum Engine RPM) | 4400 ft-lb 5965.6 Nm |
| Maximum Spindle Torque (High at Maximum Engine RPM) | 3000 ft-lb 4067.5 Nm |
| Maximum Spindle Speed at Max Engine RPM | 227 rpm |
| Minimum Bore Diameter | 4 in 10.2 cm |
| Maximum Ground Drive Speed at Maximum Engine RPM | 3.3 mph 5.3 km/h |
| Automated Rod Loader | Yes |
| Noise Level at Operator's Ear | 82.9 dB(A) |
| Guaranteed sound power (CE-rating) | 104 dB(A) |
| Fluid Capacities | |
| Fuel Tank | 44 gal 166.6 L |
| Hydraulic Tank | 55 gal 208.2 L |
| Hydraulic System | 65 gal 246.1 L |
| Drilling Fluid System Option One | |
| Maximum Flow | 50 gpm 189.3 L/min |
| Maximum Pressure | 1050 psi 72.4 bar |
| Brand | Aplex |
| On Board Tank Capacity | 6 gal 22.7 L |
| Drilling Fluid System Option Two | |
| Maximum Flow | 70 gpm 265 L/min |
| Maximum Pressure | 1100 psi 75.8 bar |
| Brand | Aplex |
| On Board Tank Capacity | 6 gal 22.7 L |
| Features | |
| Breakout System | Standard hydraulic vise |
| Drilling Lights | Standard |
| Flow Indicator | Standard |
| Stakedown System | Standard |
| Cab | Optional |
| Strike Alert | Standard |
| Remote Lockout | Standard |
