Features
Top of its class
The class-leading 167-fpm (50.9-m/min) carriage speed and rotational speeds of 257 rpm help you install more linear feet per day.
Hydraulic circuit
A newly designed hydraulic circuit offers additional power for drilling and maneuvering around the jobsite, helping operators power up curbs and slopes to work more efficiently.
Faster tracking speed
The 3.3-mph (5.3-km/h) tracking speed gets you from one setup to the next sooner.
Onboard diagnostics
Simplify machine monitoring with onboard diagnostics.
Dual joysticks
Common dual joysticks on the current Vermeer drill lineup assist in operator efficiency and training.
Specs
| General Dimensions and Weights | |
| Length (Minimum Transport) | 204 in |
| Width (Minimum Transport) | 47.5 in |
| Height (Minimum Transport) | 74 in |
| Weight | 11700 lbs |
| Angle of Approach | 18 deg |
| Engine | |
| Make and Model | Deutz TD2.9 |
| Fuel Type | Low sulfur diesel |
| Maximum Engine RPM | 2600 rpm |
| Gross Horsepower | 74 hp |
| Displacement | 177 cu-in |
| Aspiration | Turbo charged |
| Cooling Method | Liquid |
| Noise Level at Operator's Ear | 86.5 dB(A) |
| Emissions rating | Tier 4i (EU Stage IIIA) |
| ENGINE OPTION TWO | |
| Make and Model | Deutz TD2.9 |
| Fuel Type | Ultra-low sulfur diesel |
| Maximum Engine RPM | 2600 rpm |
| Gross Horsepower | 74 hp |
| Displacement | 177 cu-in |
| Aspiration | Turbocharged |
| Cooling Method | Liquid |
| Noise Level at Operator's Ear | 86.5 dB(A) |
| Emissions rating | Tier 4 Final (EU Stage IV) |
| ENGINE - OPTION THREE | |
| Make and Model | Deutz TD2.9 |
| Fuel Type | Ultra-low sulfur diesel |
| Maximum Engine RPM | 2600 rpm |
| Gross Horsepower | 74 hp |
| Displacement | 177 cu-in |
| Cooling Method | Liquid |
| Aspiration | Turbocharged |
| Noise Level at Operator's Ear | 91 dB(A) |
| Emissions rating | Tier 4 Final (EU Stage V) |
| Operational | |
| Thrust | 19500 lbs |
| Pullback | 19500 lbs |
| Maximum Carriage Speed at Maximum Engine RPM | 160 ft/min |
| Maximum Carriage Speed in Low at Maximum Engine RPM | 114 ft/min |
| Maximum Spindle Torque (Low at Maximum Engine RPM) | 2250 ft-lb |
| Maximum Spindle Speed at Max Engine RPM | 257 rpm |
| Minimum Bore Diameter | 3 in |
| Maximum Ground Drive Speed at Maximum Engine RPM | 3.3 mph |
| Automated Rod Loader | Semi-automated |
| Guaranteed sound power (CE-rating) | 106 dB(A) |
| Drill Rack Angle | 17 deg |
| DRILLING FLUID SYSTEM OPTION ONE | |
| Maximum Flow | 25 gpm |
| Maximum Pressure | 1000 psi |
| FEATURES | |
| Breakout System | Standard hydraulic vice |
| Drilling Lights | Optional |
| Flow Indicator | Standard |
| Stakedown System | Standard |
| Strike Alert | Standard |
| Remote Lockout | Standard |
| Operator Presence | Standard |
