Features
SAVE SPACE AND TIME
This machine boasts 1500 gal (5678.1 L) of freshwater storage throughout four 500 gal (1892.7 L) tanks that hold both fresh water and slurry. As the freshwater tanks empty, they begin to fill with slurry – never wasting valuable space on the machine.
MAINTAIN SUCTION
The airlock rotates continuously, discharging solids and liquids while maintaining vacuum within the system.
REMOTE CONTROL
Features a full-function remote control, allowing one-person operation of the boom, vac, conveyer, separation and dig pump.
DRIVE CONFIDENTLY
The effective weight distribution across a heavy-duty front axle and rear tandem drive axles allows you to drive confidently with a return weight under 54,000 lb (24,494 kg) when at the recommended full capacity of 10.5 ppg (1.26 sg) of slurry.
KEEP ON RUNNING
A hydraulic PTO helps keep you running and saves time because you do not need to shift power back and forth to the vac and truck.
CONVEY YOUR MATERIAL
Place solids separated from slurry where you want it with a convenient built-in conveyor belt that rotates 180-degrees and discharges 14 ft (4.3 m) out and up to 80” (203.2 cm).
Specs
| DIMENSIONS AND WEIGHTS | |
| Overall Length | 432 in |
| Truck Width | 102 in |
| Body Width | 98 in |
| Overall Height | 150 in |
| Wheel Base | 282 in |
| Tandem Axle Spread | 54 in |
| Cab to Tandem Axle | 214 in |
| Gross Vehicle Weight Rating (GVWR) | 60000 lbs |
| Gross Axle Weight Rating - Steering Axle | 20000 lbs |
| Gross Axle Weight Rating - Tandem Axle | 40000 lbs |
| Curb Weight | 39000 lbs |
| Maximum Recommended Loaded Weight | 54000 lbs |
| TRUCK | |
| Model | Kenworth T880 |
| Engine | Paccar MX13 |
| Engine Power | 455 hp |
| Transmission | 4500 RDS Allison Transmission |
| Drivetrain | PTO, Chelsea 870 |
| TANK CAPACITIES | |
| Number of Tanks | 4 |
| Tank Capacity - Each | 500 gal |
| Maximum Water Capacity | 1500 gal |
| Maximum Slurry Capacity | 1300 gal at 10.5 ppg (1.36 SG) |
| FULL HYDRAULIC BOOM - STANDARD | |
| Maximum Reach | 252 in |
| Horizontal Travel | 84 in |
| Rotation | 260 deg |
| Vertical Travel at Maximum Reach | 120 in |
| FULL HYDRAULIC CONVEYOR - STANDARD | |
| Maximum Reach | 168 in |
| Rotation | 180 deg |
| Maximum Discharge Height | 80 in |
| Belt Width | 18 in |
| WATER SYSTEM | |
| Maximum Flow | 10 gpm |
| Maximum Pressure | 3000 psi |
| Pressure Adjustment | Electronic |
| Strainer | 100 |
| Low Water Shutoff | Electronic |
| Hose Reel Type | Spring Retract |
| Water Hose Length | 75 ft |
| VACUUM | |
| Maximum Vacuum CFM | 3400 cfm |
| Maximum Vacuum | 18 inHg (609.5 Mbar) |
| Hose Diameter | 6 in |
| Number of Cyclones | 6 |
| Type of Filters | 2 micron washable poly |
| Blower Silencer | Standard |
| Reverse Pressure | Standard |
| Maximum Reverse Pressure | 5 psi |
| CLEANING SYSTEM | |
| Number of Shakers | 1 - Double deck |
| Shaker Bed Opening Width | 1 in |
| Shaker Bed Area | 19.3 sq-ft (1.8 sq-m) |
| CONTROLS | |
| Control Panel | Electronic display with 7" screen |
| Wireless Remote | Dual joystick wireless remote |
| PTO Activation | Hydraulic |
| OPTIONS | |
| Cold Weather EnclosureYes | |
| In-tank Heaters | 104,000 BTU (109,725,809 Joules) glycol heater and heat exchangers |
| Dig Pump Water Heater | 420,000 BTU (443,123,458 Joules) diesel fired broiler |
