Features
TSUNAMI ULTRALIGHT BOOM
This 8-in (20.3-cm) boom is constructed out of strenx performance steel, making it lighter than a traditional unit.
JUROP HELIX 1,500 VACUUM PUMP
The 4,800 cfm @ 27 hg (135.9 m³/min @ 2.7 kg) PD blower driven by the OMSI transfer case with blower soft-start engagement.
OMSI TRANSMISSION
The OMSI 500-hp (373-kW) transmission includes a power clutch for blower engagement that reduces stress on transmission.
IFM ELECTRONICS
Industry-leading IFM industrial controller that monitors the system's temperature, pressure and vacuum sensors. It also allows the operator to see the engine instruments, chassis instruments and the vac instruments on the belly pack.
WATER SYSTEM
The water system is a Pratisolli 13 gpm @ 3,000 psi (50.7 L/min @ 20,684.3 kPa) water pump.
BOILER
The boiler is an Easy Kleen 420K BTU diesel-fired boiler with coils rated at 5,000 psi (34,473 kPa).
REVERSE PRESSURE
Enables pressure discharge and transfer of fluid capabilities.
Specs
| TRUCK | |
| Length | 394 in (1001 cm) |
| Width | 101.8 in (258 cm) |
| Empty weight | 34000 lbs (15422 kg) |
| Height | 134.5 in (342 cm) |
| Gross Vehicle Weight Rating (GVWR) | 76000 lbs (26308 kg) |
| Truck model | Kenworth T880 |
| Engine | PACCAR MX |
| Engine model | MX11L 430 hp |
| Horsepower | 430 hp (320.7 kW) |
| Transmission | 6-speed Allison 4500 RDS with PTO option |
| ENGINE | |
| Make and Model | PACCAR MX-11 |
| Horsepower | 430 hp (320.7 kW) |
| Fuel tank capacity or type | 135 gal (511 L) |
| WATER TANK | |
| Water capacity | 850 gal (3217.6 L) |
| Number of Tanks | 1 |
| High pressure pump flow rate | 13 gpm (50.7 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 75 ft (22.9 m) |
| Low Water Shutoff | Electronic sensor indicators |
| SPOIL TANK | |
| Spoil tank capacity | 8 cu-yd (6.1 cu-m) |
| Door type | Full radius, half-moon rear door |
| Tank Lift Type | 3-stage lift cycliner |
| VACUUM | |
| Type of Filters | Dual cyclonic |
| Hose width/diameter | 8 in |
| Vacuum | 4800 cfm (135.9 cubic m/min) |
| Vacuum blower type | Jurop Helix 1500 |
| Vacuum Mercury | 27 inHg (0.9 bar) |
| CONTROL PANEL | |
| Gauges | Digital on IFM processor 12-in screen |
| BOOM | |
| Reach | 21 ft (6.4 m) |
| Hose diameter | 8 in (20.3 cm) |
| Remote ControlI | FM wireless |
| OPTIONS | |
| Hot box | Easy Kleen - 420K BTU |
| Hydraulic centrifugal 4-in pump | Optional |
