Features
CYCLONE FOUR-WAY VALVE SILENCER (CVS) FILTRATION SYSTEM
The CVS filter housing has a .5 micron filtration that contains the four-way valve for reverse pressure and an oversized silencer for quiet operation. The silencer is located inside the 28-in (71-cm) diameter cyclone.
REAR HYDRAULIC CLAW DOOR
Rear hydraulic claw door has an over-center locking mechanism for a no-fuss positive lock and unlock.
I BEAM TRAILER
Units are built from start to finish at our factory, including the trailer which consists of a sturdy I beam construction.
STRONG ARM (OPTION)
With 270-degree rotation, the strong arm supports the weight of the vacuum hose, and the roller head allows for ease of handling by allowing smooth, fluid movements and adjustments.
SIDE HOSE AND TOOLING STORAGE (OPTION)
The new side hose and tooling (SHT) package allows for 60 ft (18 m) of suction hose storage on a trailer-mounted unit. This option doubles the traditional 30-ft (9-m) hose storage.
FLOWMASTER (OPTION)
The FlowMaster option can be used to hydraulically exercise water valves and hydrants, making sure they will work properly in times of need.
Specs
| TRAILER | |
| Compatibility | 500-gal (1892.7-L) spoil tank option |
| Length | 231 in (586.7 cm) |
| Width | 92 in (234 cm) |
| Height | 95 in (241 cm) |
| Empty weight | 6300 lbs (2807.7 kg) |
| Gross Vehicle Weight Rating (GVWR) | 9995 lbs (4534 kg)/12000 lbs (5443.1 kg) |
| Trailer axles | (2) 7000 lbs (3175 kg) |
| Hitch Type | Pintle |
| TRAILER - OPTION TWO | |
| Compatibility | 800-gal (3028.3-L) spoil tank option |
| Length | 268.8 in (682.8 cm) |
| Width | 92 in (234 cm) |
| Height | 95 in (241 cm) |
| Empty weight | 7400 lbs (3357 kg) |
| Gross Vehicle Weight Rating (GVWR) | 14000 lbs (6350 kg) |
| Trailer axles | (2) 7000 lbs (3175 kg) |
| Hitch Type | Pintle |
| TRAILER - OPTION THREE | |
| Compatibility | 1200-gal (4542.5-L) spoil tank option |
| Length | 265 in (673 cm) |
| Width | 102 in (259 cm) |
| Height | 122 in (310 cm) |
| Empty weight | 9400 lbs (4264 kg) |
| Gross Vehicle Weight Rating (GVWR) | 24000 lbs (10886.2 kg) |
| Trailer axles | (2) 12000 lbs (5443.1 kg) |
| Hitch Type | Pintle |
| TRAILER - OPTION FOUR | |
| Compatibility | 500-gal (1892.7-L) heavy spoil tank option |
| Length | 231 in (586.7 cm) |
| Width | 97 in (246.4 cm) |
| Height | 95 in (241 cm) |
| Empty weight | 6300 lbs (2858 kg) |
| Gross Vehicle Weight Rating (GVWR) | 14000 lbs (6350 kg) |
| Trailer axles | (2) 7000 lbs (3175 kg) |
| Hitch Type | Pintle |
| TRAILER - OPTION FIVE | |
| Compatibility | 800-gal (3028.3-L) heavy spoil tank option |
| Length | 268.8 in (682.8 cm) |
| Width | 102 in (259 cm) |
| Height | 95 in (241 cm) |
| Empty weight | 7500 lbs (3402 kg) |
| Gross Vehicle Weight Rating (GVWR) | 20000 lbs (9071.9 kg) |
| Trailer axles | (2) 10000 lbs (4535.9 kg) |
| Hitch Type | Pintle |
| ENGINE | |
| Make and Model | Kohler Diesel Tier 4 Final |
| Horsepower | 24 hp (17.9 kW) |
| Fuel tank capacity or type | 30 gal (114 L) |
| Enclosure | Yes |
| WATER TANK | |
| Compatibility | 500-gal (1892.7-L) spoil tank option |
| Water capacity | 200 gal (757 L) |
| Number of Tanks | 2 |
| High pressure pump flow rate | 4 gpm (15.1 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Yes |
| WATER TANK - OPTION TWO | |
| Compatibility | 800-gal (3028.3-L) spoil tank option |
| Water capacity | 200 gal (757 L) |
| Number of Tanks | 2 |
| High pressure pump flow rate | 4 gpm (15.1 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Yes |
| WATER TANK - OPTION THREE | |
| Compatibility | 1200-gal (4542.5-L) spoil tank option |
| Water capacity | 400 gal (1514 L) |
| Number of Tanks | 2 |
| High pressure pump flow rate | 4 gpm (15.1 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Yes |
| WATER TANK - OPTION FOUR | |
| Compatibility | 500-gal (1892.7-L) heavy spoil tank option |
| Water capacity | 300 gal (1136 L) |
| Number of Tanks | 2 |
| High pressure pump flow rate | 4 gpm (15.1 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Yes |
| WATER TANK - OPTION FIVE | |
| Compatibility | 800-gal (3028.3-L) heavy spoil tank option |
| Water capacity | 400 gal (1514 L) |
| Number of Tanks | 2 |
| High pressure pump flow rate | 4 gpm (15.1 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Yes |
| SPOIL TANK | |
| Compatibility | 500-gal (1892.7-L) spoil tank option |
| Spoil tank capacity | 500 gal (1892.7 L) |
| Door type | Hydraulic |
| Tank Lift Type | Hydraulic |
| SPOIL TANK - OPTION TWO | |
| Compatibility | 800-gal (3028.3-L) spoil tank option |
| Spoil tank capacity | 800 gal (3028.3 L) |
| Door type | Hydraulic |
| Tank Lift Type | Hydraulic |
| SPOIL TANK - OPTION THREE | |
| Compatibility | 1200-gal (4542.5-L) spoil tank option |
| Spoil tank capacity | 1200 gal (4542.5 L) |
| Door type | Hydraulic |
| Tank Lift Type | Hydraulic |
| SPOIL TANK - OPTION FOUR | |
| Compatibility | 500-gal (1892.7-L) heavy spoil tank option |
| Spoil tank capacity | 500 gal (1892.7 L) |
| Door type | Hydraulic |
| Tank Lift Type | Hydraulic |
| SPOIL TANK - OPTION FIVE | |
| Compatibility | 800-gal (3028.3-L) heavy spoil tank option |
| Spoil tank capacity | 800 gal (3028.3 L) |
| Door type | Hydraulic |
| Tank Lift Type | Hydraulic |
| VACUUM | |
| Type of Filters | Cartridge filter 0.5 microns |
| Hose length | 30 ft (9 m) |
| Hose width/diameter | 3 in |
| Vacuum | 580 cfm (16 cubic m/min) |
| Vacuum blower type | PD blower |
| Vacuum Mercury | 14 inHg (0.4 bar) |
| CONTROL PANEL | |
| Controls | Curbside |
| Gauges | Analog |
| OPTIONS | |
| Hot box | Optional |
| Strong arm | Optional |
| Side hose and tooling storage (SHT package) | Optional |
| Recirculation kit | Optional |
| Flowmaster | Optional |
| Hydraulic jack | Optional |
| Reverse Pressure | Standard |
