Features
CYCLONE FOUR-WAY VALVE SILENCER (CVS) FILTRATION SYSTEM
The CVS filter housing has a .5 micron filtration that contains the four-way valve for reverse pressure and an oversized silencer for quiet operation. The silencer is located inside the 28-in (71-cm) diameter cyclone.
I BEAM TRAILER
Units are built from start to finish at our factory, including the trailer which consists of a sturdy I beam construction.
SIDE HOSE AND TOOLING STORAGE (OPTION)
The new side hose and tooling (SHT) package allows for 60 ft (18 m) of suction hose storage on a trailer-mounted unit. This option doubles the traditional 30-ft (9-m) hose storage.
STRONG ARM (OPTION)
With 270-degree rotation, the strong arm supports the weight of the vacuum hose, and the roller head allows for ease of handling by allowing smooth, fluid movements and adjustments.
HYDRAULIC BOOM (OPTION)
The hydraulic boom offers a full six-way function, wireless remote with vacuum valve operation, 330-degree rotation, remote water jet for ease of cleanout and a 5-in (12.7-cm) hose with quick connect to 4-in (10.2-cm) tooling.
FLOWMASTER (OPTION)
The FlowMaster option can be used to hydraulically exercise water valves and hydrants, making sure they will work properly in times of need.
Specs
| TRAILER | |
| Compatibility | 500-gal (1892.7-L) spoil tank option |
| Length | 231 in (586.7 cm) |
| Width | 92 in (234 cm) |
| Height | 95 in (241 cm) |
| Empty weight | 6300 lbs (2858 kg) |
| Gross Vehicle Weight Rating (GVWR) | 9995 lbs (4533 kg) |
| Trailer axles | (2) 7000 lbs (3175 kg) |
| Hitch Type | Pintle |
| TRAILER - OPTION TWO | |
| Compatibility | 800-gal (3028.3-L) spoil tank option |
| Length | 268.8 in (682.8 cm) |
| Width | 92 in (234 cm) |
| Height | 95 in (241 cm) |
| Empty weight | 7800 lbs (3538 kg) |
| Gross Vehicle Weight Rating (GVWR) | 14000 lbs (6350 kg) |
| Trailer axles | (2) 7000 lbs (3175 kg) |
| Hitch Type | Pintle |
| TRAILER - OPTION THREE | |
| Compatibility | 1200-gal (4542.5-L) spoil tank option |
| Length | 265 in (673 cm) |
| Width | 102 in (259 cm) |
| Height | 122 in (309.8 cm) |
| Empty weight | 9800 lbs (4445 kg) |
| Gross Vehicle Weight Rating (GVWR) | 24000 lbs (10886.2 kg) |
| Trailer axles | (2) 12000 lbs (5443.1 kg) |
| Hitch Type | Pintle |
| TRAILER - OPTION FOUR | |
| Compatibility | 500-gal (1892.7-L) heavy spoil tank option |
| Length | 231 in (586.7 cm) |
| Width | 97 in (246cm) |
| Height | 95 in (241 cm) |
| Empty weight | 6700 lbs (3039 kg) |
| Gross Vehicle Weight Rating (GVWR) | 14000 lbs (6350 kg) |
| Trailer axles | (2) 7000 lbs (3175 kg) |
| Hitch Type | Pintle |
| TRAILER - OPTION FIVE | |
| Compatibility | 800-gal (3028.3-L) heavy spoil tank option |
| Length | 268.8 in (682.8 cm) |
| Width | 102 in (259 cm) |
| Height | 95 in (241 cm) |
| Empty weight | 8000 lbs (3629 kg) |
| Gross Vehicle Weight Rating (GVWR) | 20000 lbs (9071.9 kg) |
| Trailer axles | (2) 10000 lbs (4535.9 kg) |
| Hitch Type | Pintle |
| SKID | |
| Compatibility | 800-gal (3028.3-L) heavy spoil tank option |
| Length | 229 in (582 cm) |
| Width | 99 in (252 cm) |
| Height | 82 in (208 cm) |
| Empty Weight | 6400 lbs (2903 kg) |
| ENGINE | |
| Make and Model | Yanmar Diesel Tier 4 Final |
| Horsepower | 49 hp (36.5 kW) |
| Fuel tank capacity or type | 30 gal (114 L) |
| Enclosure | Yes |
| WATER TANK | |
| Compatibility | 500-gal (1892.7-L) spoil tank option |
| Water capacity | 200 gal (757 L) |
| Number of Tanks | 2 |
| High pressure pump flow rate | 4 gpm (15.1 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Electric |
| WATER TANK - OPTION TWO | |
| Compatibility | 800-gal (3028.3-L) spoil tank option |
| Water capacity | 200 gal (757 L) |
| Number of Tanks | 2 |
| High pressure pump flow rate | 4 gpm (15.1 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Electric |
| WATER TANK - OPTION THREE | |
| Compatibility | 1200-gal (4542.5-L) spoil tank option |
| Water capacity | 400 gal (1514 L) |
| Number of Tanks | 2 |
| High pressure pump flow rate | 4 gpm (15.1 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Electric |
| WATER TANK - OPTION FOUR | |
| Compatibility | 500-gal (1892.7-L) heavy spoil tank option |
| Water capacity | 300 gal (1136 L) |
| Number of Tanks | 2 |
| High pressure pump flow rate | 4 gpm (15.1 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Electric |
| WATER TANK - OPTION FIVE | |
| Compatibility | 800-gal (3028.3-L) heavy spoil tank option |
| Water capacity | 400 gal (1514 L) |
| Number of Tanks | 2 |
| High pressure pump flow rate | 4 gpm (15.1 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Electric |
| SPOIL TANK | |
| Compatibility | 500-gal (1892.7-L) spoil tank option |
| Spoil tank capacity | 500 gal (1892.7 L) |
| Door type | Hydraulic |
| Tank Lift Type | Hydraulic |
| SPOIL TANK - OPTION TWO | |
| Compatibility | 800-gal (3028.3-L) spoil tank option |
| Spoil tank capacity | 800 gal (3028.3 L) |
| Door type | Hydraulic |
| Tank Lift Type | Hydraulic |
| SPOIL TANK - OPTION THREE | |
| Compatibility | 1200-gal (4542.5-L) spoil tank option |
| Spoil tank capacity | 1200 gal (4542.5 L) |
| Door type | Hydraulic |
| Tank Lift Type | Hydraulic |
| SPOIL TANK - OPTION FOUR | |
| Compatibility | 500-gal (1892.7-L) heavy spoil tank option |
| Spoil tank capacity | 500 gal (1892.7 L) |
| Door type | Hydraulic |
| Tank Lift Type | Hydraulic |
| SPOIL TANK - OPTION FIVE | |
| Compatibility | 800-gal (3028.3-L) heavy spoil tank option |
| Spoil tank capacity | 800 gal (3028.3 L) |
| Door type | Hydraulic |
| Tank Lift Type | Hydraulic |
| VACUUM | |
| Type of Filters | Cartridge filter 0.5 microns |
| Hose length | 30 ft (9 m) |
| Hose width/diameter | 4 in |
| Vacuum | 1000 cfm (28 cubic m/min) |
| Vacuum blower type | PD blower |
| Vacuum Mercury | 16 inHg (0.6 bar) |
| CONTROL PANEL | |
| Controls | Curbside |
| Gauges | Analog and digital |
| BOOM | |
| Availability | Optional |
| Weight | 400 lbs (181 kg) |
| Reach | 15 ft (4.6 m) |
| Movement | 300 deg |
| Remote Control | Wireless |
| OPTIONS | |
| Strong arm | Optional |
| Side hose and tooling storage (SHT package) | Optional |
| Recirculation kit | Optional |
| Flowmaster | Optional - not available on non-heavy modesl |
| Hydraulic jack | Optional |
| Reverse Pressure | Standard |
