Features
CYCLONE FOUR-WAY VALVE SILENCER (CVS) FILTRATION SYSTEM
The CVS filter housing has a .5 micron filtration that contains the four-way valve for reverse pressure and an oversized silencer for quiet operation. The silencer is located inside the 28-in (71-cm) diameter cyclone.
REAR HYDRAULIC CLAW DOOR
Rear hydraulic claw door has an over-center locking mechanism for a no-fuss positive lock and unlock.
TOOL BOX
Two shelf storage boxes located on the driver's side to store jobsite tools.
STRONG ARM (OPTION)
With 270-degree rotation, the strong arm supports the weight of the vacuum hose, and the roller head allows for ease of handling by allowing smooth, fluid movements and adjustments.
HYDRAULIC BOOM (OPTION)
The hydraulic boom offers a full six-way function, wireless remote with vacuum valve operation, 330-degree rotation, remote water jet for ease of cleanout and a 5-in (12.7-cm) hose with quick connect to 4-in (10.2-cm) tooling.
PTO DRIVEN
All components are controlled from the truck, eliminating the extra weight, space and cost of the pony motor.
Specs
| TRUCK | |
| Length | 345 in (876.3 cm) |
| Width | 102 in (259.1 cm) |
| Empty weight | 16850 lb (7643 kg) |
| Height | 120 in (305 cm) without boom |
| Gross Vehicle Weight Rating (GVWR) | 26000 lb (11793 kg) |
| Truck model | Ford F-650 |
| Engine | PTO driven |
| TRUCK - OPTION TWO | |
| Length | 345 in (876.3 cm) |
| Width | 102 in (259 cm) |
| Empty weight | 18000 lb (8165 kg) |
| Height | 120 in (305 cm) without boom |
| Gross Vehicle Weight Rating (GVWR) | 33000 lb (14969 kg) |
| Truck model | Ford F-750 |
| Engine | PTO driven |
| WATER TANK | |
| Water capacity | 400 gal (1514 L) |
| Number of Tanks | 2 |
| High pressure pump flow rate | 4 gpm (15.1 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Electric |
| SPOIL TANK | |
| Spoil tank capacity | 800 gal (3028.3 L) |
| Door type | Hydraulic |
| Tank Lift Type | Scissor lift |
| VACUUM | |
| Type of Filters | Cartridge filter 0.5 microns |
| Hose length | 30 ft (9.1 m) |
| Hose width/diameter | 4 in (10.2 cm) |
| Vacuum | 1000 cfm (28 cubic m/min) |
| Vacuum blower type | PD blower |
| Vacuum Mercury | 16 inHg (0.6 bar) |
| CONTROL PANEL | |
| Controls | Curbside |
| BOOM | |
| Availability | Optional |
| Weight | 400 lb (181 kg) |
| Reach | 15 ft (4.6 m) |
| Movement | 330 deg |
| Remote Control | Wireless |
| OPTIONS | |
| Hot box | Optional |
| Strong arm | Optional |
| Recirculation kit | Optional |
| Reverse Pressure | Standard |
