Features
HYDRAULIC TILT TANK
Efficiently offload debris.
40-GALLON WATER TANK
Has 40 gal (151.4 L) of fresh water with 4 gpm (15 L/min) at 3,000 psi water pump.
FLOWMASTER (OPTION)
The FlowMaster option can be used to hydraulically exercise water valves and hydrants, making sure they will work properly in times of need.
I BEAM TRAILER
Units are built from start to finish at our factory, including the trailer which consists of a sturdy I beam construction.
Specs
| TRAILER | |
| Length | 196 in (498 cm) |
| Width | 72 in (188.9 cm) |
| Height | 60 in (152.4 cm) |
| Empty weight | 2100 lbs (953 kg) |
| Gross Vehicle Weight Rating (GVWR) | 3500 lbs (1587 kg) |
| Trailer axles | (1) 3500 lbs (1587 kg) |
| Hitch Type | Pintle |
| SKID | |
| Length | 150 in (381 cm) |
| Width | 55 in (140 cm) |
| Height | 46 in (117 cm) |
| Empty weight | 1800 lbs (816 kg) |
| ENGINE | |
| Make and Model | Kohler EFI Gas |
| Horsepower | 27 hp (20 kW) |
| Fuel tank capacity or type | 5 gal (19 L) |
| WATER TANK | |
| Water capacity | 40 gal (151 L) |
| Number of Tanks | 1 |
| High pressure pump flow rate | 4 gpm (15.1 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Yes |
| SPOIL TANK | |
| Spoil tank capacity | 150 gal (567.8 L) |
| Door type | Manual wheel locking system |
| Tank Lift Type | Hydraulic tilt |
| VACUUM | |
| Type of Filters | 0.5 micron filtration |
| Hose length | 30 ft (9 m) |
| Hose width/diameter | 3 in |
| Vacuum | 580 cfm (16 cubic m/min) |
| Vacuum blower type | PD blower |
| Vacuum Mercury | 13 inHg (0.3 bar) |
| CONTROL PANEL | |
| Controls | Curbside |
| Gauges | Analog |
| OPTIONS | |
| Flowmaster | Optional |
