Features
THREE-STAGE CYCLONIC FILTRATION
Engineered to help prolong filter and blower life, the system is suitable for wet and dry applications. The cyclones use a tuned vortex system in which the outer vortex spiral forces small particles to fall into a separate canister. The filtered stream then passes up through the inner cyclone tube and is carried to the final poly filter.
CAM-OVER REAR DOOR
Provides a 360-degree positive seal, even under reverse pressure without additional clamping requirements. The highly reliable cam-over door has no in-tank moving parts, so all maintenance is external.
IN-TANK WASHDOWN
Delivers a high-pressure water spray to the tank interior helping to simultaneously dump material and clean the inside of the tank. Minimizes cleanup time and makes it efficient to remove difficult debris.
ECONOMICAL OPERATION
Delivers fuel savings and has minimized maintenance costs compared to truck engine services. Offers the versatility to mount on new or used truck chassis or on off-road crawler carriers.
HYDRAULIC BOOM (OPTION)
Exclusive telescoping boom maintains hose length during extension and incorporates a remote-controlled hydraulic valve for vacuum shutoff. Available with manual or hydraulic rotation.
MODULAR DESIGN
Mount on a new or used double-frame truck chassis, on- or off-road crawler carriers or hook truck bodies for access to difficult projects.
Specs
| SKID | |
| Compatibility | 500-gal (1892.7-L) spoil tank option |
| Length | 193 in (490 cm) |
| Width | 95 in (241 cm) |
| Height | 84 in (213 cm) |
| Empty weight | 7473 lbs (3375 kg) |
| SKID - OPTION TWO | |
| Compatibility | 800-gal (3028.3-L) spoil tank option |
| Length | 211 in (536 cm) |
| Width | 97 in (246 cm) |
| Height | 86 in (218 cm) |
| Empty weight | 8050 lbs (3651kg) |
| SKID - OPTION THREE | |
| Compatibility | 1200-gal (4542.5-L) spoil tank option |
| Length | 267 in (678 cm) |
| Width | 97 in (246 cm) |
| Height | 92 in (234 cm) |
| Empty weight | 8850 lbs (3997 kg) |
| ENGINE | |
| Make and Model | Deutz Tier 4 Final diesel |
| Horsepower | 74 hp (55 kW) |
| Fuel tank capacity or type | 22 gal (83.3 L) |
| Enclosure | Yes |
| WATER TANK | |
| Compatibility | 500-gal (1892.7-L) spoil tank option |
| Water capacity | 250 gal (946 L) |
| Number of Tanks | 2 |
| High pressure pump flow rate | 8 gpm (34 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Electric |
| WATER TANK - OPTION TWO | |
| Compatibility | 800-gal (3028.3-L) spoil tank option |
| Water capacity | 410 gal (1552 L) |
| Number of Tanks | 2 |
| High pressure pump flow rate | 8 gpm (34 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Electric |
| WATER TANK - OPTION THREE | |
| Compatibility | 1200-gal (4542.5-L) spoil tank option |
| Water capacity | 410 gal (1552 L) |
| Number of Tanks | 2 |
| High pressure pump flow rate | 8 gpm (34 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Electric |
| SPOIL TANK | |
| Compatibility | 500-gal (1892.7-L) spoil tank option |
| Spoil tank capacity | 500 gal (1892.7 L) |
| Door type | Cam-over hydraulic |
| Tank Lift Type | Dual cylinder |
| SPOIL TANK - OPTION TWO | |
| Compatibility | 800-gal (3028.3-L) spoil tank option |
| Spoil tank capacity | 800 gal (3028.3 L) |
| Door type | Cam-over hydraulic |
| Tank Lift Type | Dual cylinder |
| SPOIL TANK - OPTION THREE | |
| Compatibility | 1200-gal (4542.5-L) spoil tank option |
| Spoil tank capacity | 1200 gal (4542.5 L) |
| Door type | Cam-over hydraulic |
| Tank Lift Type | Dual cylinder |
| VACUUM | |
| Type of Filters | 2 micron washable |
| Hose length | (3) 10 ft (3 m) |
| Hose width/diameter | 4 in |
| Vacuum | 1200 cfm (34 cubic m/min) |
| Vacuum blower type | PD blower |
| Vacuum Mercury | 15 inHg (0.5 bar) |
| CONTROL PANEL | |
| Controls | Curbside |
| Gauges | Analog |
| BOOM | |
| Availability | Optional |
| Weight | 1200 lbs (544.3 kg) |
| Reach | 14 ft (4.3 m) |
| Movement | 270 deg on 14-in turret bearings |
| Remote Control | Wireless |
| JETTER PUMP | |
| Availability | Optional |
| Water flow | 12 gpm/18 gpm |
| Water pressure | 3000 psi (206.8 bar)/2000 psi (137.9 bar) |
| Jetter hose length | 500 ft |
| Jetter hose diameter | .5 in |
| AIR COMPRESSOR | |
| Availability | Optional |
| Air Flow | 185 cfm |
| Air Pressure | 100 psi |
| Air Hose Length | 50 ft |
| Air Hose Size | 1 in |
| OPTIONS | |
| Hot box | Optional |
| Strong arm | Optional on 500-gal (1,892.7-L) and 800-gal (3,028.3-L) spoil tank options; not available on 1200-gal (4542.5-L) spoil tank option |
| Recirculation kit | Optional |
| Reverse Pressure | Standard |
