Features
MODULAR DESIGN
Mount on a new or used double-frame truck chassis, on- or off-road crawler carriers or hook truck bodies for access to difficult projects.
HYDRAULIC BOOM (OPTION)
Exclusive telescoping boom maintains hose length during extension and incorporates a remote-controlled hydraulic valve for vacuum shutoff. Available with manual or hydraulic rotation.
ECONOMICAL OPERATION
Delivers fuel savings and has minimized maintenance costs compared to truck engine services. Offers the versatility to mount on new or used truck chassis or on off-road crawler carriers.
IN-TANK WASHDOWN
Delivers a high-pressure water spray to the tank interior helping to simultaneously dump material and clean the inside of the tank. Minimizes cleanup time and makes it efficient to remove difficult debris.
CAM-OVER REAR DOOR
Provides a 360-degree positive seal, even under reverse pressure without additional clamping requirements. The highly reliable cam-over door has no in-tank moving parts, so all maintenance is external.
THREE-STAGE CYCLONIC FILTRATION
Engineered to help prolong filter and blower life, the system is suitable for wet and dry applications. The cyclones use a tuned vortex system in which the outer vortex spiral forces small particles to fall into a separate canister. The filtered stream then passes up through the inner cyclone tube and is carried to the final poly filter.
Specs
| SKID | |
| Compatibility | 1600-gal (6055-L) spoil tank option |
| Length | 245 in (622.3 cm) |
| Width | 95.8 in (243.2 cm) |
| Height | 201 in (510.5 cm) |
| Empty weight | 11240 lbs (5109.1 kg) |
| SKID - OPTION TWO | |
| Compatibility | 2200-gal (8325-L) spoil tank option |
| Length | 306 in (77.2 cm) |
| Width | 88.8 in (225.4 cm) |
| Height | 110 in (279.4 cm) |
| Empty weight | 10700 lbs (4864.6kg) |
| SKID - OPTION THREE | |
| Compatibility | 3000-gal (11352-L) spoil tank option |
| Length | 334 in (848.4 cm) |
| Width | 94 in (238.8 cm) |
| Height | 117 in (297.2 cm) |
| Empty weight | 12117 lbs (5507.7 kg) |
| ENGINE | |
| Make and Model | Deutz Tier 4 Final diesel |
| Horsepower | 74 hp (55 kW) |
| Fuel tank capacity or type | 22 gal (83.3 L) |
| Enclosure | Yes |
| WATER TANK | |
| Water capacity | (1) 410 gal (1552 L) or (1) 925 gal (3501.5 L) |
| Number of Tanks | 1 |
| High pressure pump flow rate | 8 gpm (30.3 L/min)/5.6 gpm (21.2 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Electric |
| SPOIL TANK | |
| Compatibility | 1600-gal (6055-L) spoil tank option |
| Spoil tank capacity | 1600-gal (6055-L) |
| Door type | Cam-over hydraulic |
| Tank Lift Type | Dual cylinder hydraulic |
| SPOIL TANK - OPTION TWO | |
| Compatibility | 2200-gal (8325-L) spoil tank option |
| Spoil tank capacity | 2200-gal (8325-L) |
| Door type | Cam-over hydraulic |
| Tank Lift Type | Dual cylinder hydraulic |
| SPOIL TANK - OPTION THREE | |
| Compatibility | 3000-gal (11352-L) spoil tank option |
| Spoil tank capacity | 3000-gal (11352-L) |
| Door type | Cam-over hydraulic |
| Tank Lift Type | Dual cylinder |
| VACUUM | |
| Type of Filters | 2 micron washable |
| Hose length | (3) 10 ft (3 m) |
| Hose width/diameter | 4 in |
| Vacuum | 1200 cfm (34 cubic m/min) |
| Vacuum blower type | PD blower |
| Vacuum Mercury | 15 inHg (0.5 bar)/23 inHg (0.8 bar) |
| CONTROL PANEL | |
| Controls | Curbside |
| Gauges | Analog |
| BOOM | |
| Availability | Optional |
| Weight | 1200 lbs (544.3 kg) |
| Reach | 14 ft (4.3 m) |
| Movement | 270 deg on 14-in turret bearings |
| Remote Control | Wireless |
| OPTIONS | |
| Hot box | Optional |
| Reverse Pressure | Standard |
