Features
ECONOMICAL OPERATION
Delivers fuel savings and has minimized maintenance costs compared to truck engine services. Offers the versatility to mount on new or used truck chassis or on off-road crawler carriers.
CAM-OVER REAR DOOR
Provides a 360-degree positive seal, even under reverse pressure without additional clamping requirements. The highly reliable cam-over door has no in-tank moving parts, so all maintenance is external.
THREE-STAGE CYCLONIC FILTRATION
Engineered to help prolong filter and blower life, the system is suitable for wet and dry applications. The cyclones use a tuned vortex system in which the outer vortex spiral forces small particles to fall into a separate canister. The filtered stream then passes up through the inner cyclone tube and is carried to the final poly filter.
IN-TANK WASHDOWN
Delivers a high-pressure water spray to the tank interior, helping to simultaneously dump material and clean the inside of the tank. Minimizes cleanup time and helps remove difficult debris.
AUTO-BELT TENSIONERS
Keeps proper belt tensions at all times and helps extend belt life.
HYDRAULIC BOOM (OPTION)
Exclusive telescoping boom maintains hose length during extension and incorporates a remote-controlled hydraulic valve for vacuum shutoff. Available with manual or hydraulic rotation.
Specs
| SKID | |
| Compatibility | 500-gal (1892.7-L) spoil tank option |
| Length | 175 in (444.5 cm) |
| Width | 97 in (246.4 cm) |
| Height | 66 in (167.6 cm) |
| Empty weight | 5450 lbs (2472.1 kg) |
| SKID - OPTION TWO | |
| Compatibility | 800-gal (3028.3-L) spoil tank option |
| Length | 203 in (516.6 cm) |
| Width | 97 in (246.4 cm) |
| Height | 68 in (167.6 cm) |
| Empty weight | 6085 lbs (2760.1 kg) |
| ENGINE | |
| Make and Model | Kubota Tier 4 Final |
| Horsepower | 49 hp (37 kW) |
| Fuel tank capacity or type | 22 gal (83.3 L) |
| Enclosure | Yes |
| WATER TANK | |
| Compatibility | 500-gal (1892.7-L) spoil tank option |
| Water capacity | 250 gal (946 L) |
| Number of Tanks | 2 |
| High pressure pump flow rate | 5.6 gpm (21.2 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Electric |
| WATER TANK - OPTION TWO | |
| Compatibility | 800-gal (3028.3-L) spoil tank option |
| Water capacity | 410 gal (1552 L) |
| Number of Tanks | 2 |
| High pressure pump flow rate | 5.6 gpm (21.2 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Electric |
| SPOIL TANK | |
| Compatibility | 500-gal (1892.7-L) spoil tank option |
| Spoil tank capacity | 500 gal (1892.7 L) |
| Door type | Cam-over hydraulic |
| Tank Lift Type | Dual cylinder |
| SPOIL TANK - OPTION TWO | |
| Compatibility | 800-gal (3028.3-L) spoil tank option |
| Spoil tank capacity | 800 gal (3028.3 L) |
| Door type | Cam-over hydraulic |
| Tank Lift Type | Dual cylinder |
| VACUUM | |
| Type of Filters | 2 micron washable |
| Hose length | (2) 15 ft (4.6 m) |
| Hose width/diameter | 4 in |
| Vacuum | 1025 cfm (29 cubic m/min) |
| Vacuum blower type | PD blower |
| Vacuum Mercury | 15 inHg (0.5 bar) |
| CONTROL PANEL | |
| Controls | Curbside |
| Gauges | Analog |
| BOOM | |
| Availability | Optional |
| Weight | 1200 lbs (544.3 kg) |
| Reach | 14 ft (4.3 m) |
| Movement | 270 deg on 14-in turret bearings |
| Remote Control | Wireless |
| OPTIONS | |
| Hot box | Optional |
| Strong arm | Optional |
| Recirculation kit | Optional |
| Reverse Pressure | Standard |
