Features
THREE-STAGE CYCLONIC FILTRATION
Designed specifically for 3,500-cfm (99.1-m³/min) “free air" blower systems, it allows for wet and dry vacuum excavation while helping to prolong filter life and minimize maintenance costs.
CAM-OVER REAR DOOR
The highly reliable cam-over design provides a 360-degree positive seal, with no additional clamping and no in-tank moving parts.
FULL-FUNCTION, WIRELESS CAN BUS CONTROLS
The radio remote monitors and controls all machine functions and vital information. Remote straps to the operator and features a machine stop.
LARGE HOSE DIAMETER
Featuring a 6-in (15.2-cm) hose diameter with a 3,500-cfm (99.1-m³/min) “free air” blower and 18 in Hg (.6 bar) to get more work done and take on big jobs.
VACUUM NEUTRAL MODE
Air is able to run and circulate through the blower without suction or vacuum in the tank, allowing the engine and blower to unload or free-run when not in use to help prolong the blower and engine life.
MODULAR DESIGN
Mount on a new or used double-frame truck chassis, on- or off-road crawler carriers or hook truck bodies for access to difficult projects.
Specs
| SKID | |
| Length | 288 in (731.5 cm) |
| Width | 100 in (254 cm) |
| Height | 111 in (280 cm) |
| Empty weight | 18320 lbs (8310 kg) |
| ENGINE | |
| Make and Model | Volvo Penta TAD572VE Tier 4 Final diesel |
| Horsepower | 215 hp (160 kW) |
| Fuel tank capacity or typeConnected to truck fuel supply | Connected to truck fuel supply |
| Enclosure | Yes |
| WATER TANK | |
| Water capacity | 600 gal (2270 L) |
| Number of Tanks | 3 |
| High pressure pump flow rate | 10 gpm (37.9 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 75 ft (22.9 m) |
| Low Water Shutoff | Electric |
| SPOIL TANK | |
| Spoil tank capacity | 1600 gal (6057 L) |
| Door type | Cam-over hydraulic |
| Tank Lift Type | Dual cylinder |
| VACUUM | |
| Type of Filters | 2 micron washable |
| Hose length | 3-5 ft (0.9-1.5 m) |
| Hose width/diameter | 6 in |
| Vacuum | 3500 "free air" cfm (99 cubic m/min) |
| Vacuum blower type | PD blower |
| Vacuum Mercury | 18 inHg (0.6 bar) |
| CONTROL PANEL | |
| Controls | Curbside |
| Gauges | Electronic display with 7-in (17.8-cm) LCD screen |
| BOOM | |
| Availability | Standard |
| Weight | 893.7 lbs (405.4 kg) |
| Reach | 14-19 ft (4.3-5.8 m) |
| Movement | 270 deg rotation |
| Remote Control | Wireless |
| OPTIONS | |
| Hot box | Optional |
