Features
.5 MICRON FILTRATION
Cyclonic filtration separator as well as a secondary filter to clean the air down to .5 micron.
REAR HYDRAULIC CLAW DOOR
Rear hydraulic claw door has an over-center locking mechanism for a no-fuss positive lock and unlock.
POLYMER LINER
The polymer liner lines the bottom half of the debris tank for ease of dumping and clean out.
STRONG ARM (OPTION)
With 270-degree rotation, the strong arm supports the weight of the vacuum hose, and the roller head allows for ease of handling by allowing smooth, fluid movements and adjustments.
REVERSE PRESSURE
Reverse pressure to offload liquids and dislodge debris in the hose.
I BEAM TRAILER
Units are built from start to finish at our factory, including the trailer which consists of a sturdy I beam construction.
Specs
| TRAILER | |
| Compatibility | 500-gal (1892.7-L) spoil tank option |
| Length | 228 in (579 cm) |
| Width | 93 in (236 cm) |
| Height | 89 in (226 cm) |
| Empty weight | 4800 lbs (2177 kg) |
| Gross Vehicle Weight Rating (GVWR) | 9995 lbs (4534 kg) |
| Trailer axles | (2) 7000 lbs (3175 kg) |
| TRAILER - OPTION TWO | |
| Compatibility | 800-gal (3028.3-L) spoil tank option |
| Length | 246 in (625 cm) |
| Width | 97 in (246 cm) |
| Height | 89 in (226 cm) |
| Empty weight | 5300 lbs (2404 kg) |
| Gross Vehicle Weight Rating (GVWR) | 14000 lbs (6350 kg) |
| Trailer axles | (2) 7000 lbs (3175 kg) |
| TRAILER - OPTION THREE | |
| Compatibility | 1200-gal (4542.5-L) spoil tank option |
| Length | 248 in (630 cm) |
| Width | 102 in (259 cm) |
| Height | 122 in (310 cm) |
| Empty weight | 7300 lbs (3311 kg) |
| Gross Vehicle Weight Rating (GVWR) | 24000 lbs (10886 kg) |
| Trailer axles | (2) 12000 lbs (5443.1 kg) |
| ENGINE | |
| Make and Model | Kohler EFI Gas |
| Horsepower | 27 hp (20.1 kW) |
| Fuel tank capacity or type | 14 gal (53 L) |
| WATER TANK | |
| Compatibility | 500-gal (1892.7-L) spoil tank option |
| Water capacity | 200 gal (757 L) |
| Number of Tanks | 2 |
| High pressure pump flow rate | 4 gpm (15.1 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Electric |
| WATER TANK - OPTION TWO | |
| Compatibility | 800-gal (3028.3-L) spoil tank option |
| Water capacity | 300 gal (1136 L) |
| Number of Tanks | 2 |
| High pressure pump flow rate | 4 gpm (15.1 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Electric |
| WATER TANK - OPTION THREE | |
| Compatibility | 1200-gal (4542.5-L) spoil tank option |
| Water capacity | 400 gal (1514 L) |
| Number of Tanks | 2 |
| High pressure pump flow rate | 4 gpm (15.1 L/min) |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 50 ft (15 m) |
| Low Water Shutoff | Electric |
| SPOIL TANK | |
| Compatibility | 500-gal (1892.7-L) spoil tank option |
| Spoil tank capacity | 500 gal (1892.7 L) |
| Door type | Hydraulic |
| Tank Lift Type | Hydraulic |
| SPOIL TANK - OPTION TWO | |
| Compatibility | 800-gal (3028.3-L) spoil tank option |
| Spoil tank capacity | 800 gal (3028.3 L) |
| Door type | Hydraulic |
| Tank Lift Type | Hydraulic |
| SPOIL TANK - OPTION THREE | |
| Compatibility | 1200-gal (4542.5-L) spoil tank option |
| Spoil tank capacity | 1200 gal (4542.5 L) |
| Door type | Hydraulic |
| Tank Lift Type | Hydraulic |
| VACUUM | |
| Type of Filters | Cartridge filter 0.5 microns |
| Hose length | 30 ft (9 m) |
| Hose width/diameter | 3 in |
| Vacuum | 580 cfm (16 cubic m/min) |
| Vacuum blower type | PD blower |
| Vacuum Mercury | 14 inHg (0.4 bar) |
| CONTROL PANEL | |
| Controls | Curbside |
| Gauges | Analog |
| OPTIONS | |
| Strong arm | Optional |
| Recirculation kit | Optional |
| Hydraulic jack | Optional |
| Reverse Pressure | Standard |
