Features
FOUR-BAR LINKAGE
Maximizes cutting width because a unique four-bar linkage moves the cutter wheel away from the machine as the boom drops.
COMPACT FOOTPRINT
Get into tight spots with side-mounted controls that are easy to reach, and an auxiliary control station that lets the operator lead or follow the machine through narrow confines.
EASY MAINTENANCE ACCESS
Reduce maintenance time through features like hinged doors and removable panels that give you easy access to service pumps.
CONFIDENCE PLUS® ASSET PROTECTION PROGRAM
Add Confidence Plus® asset protection program in your initial purchase or add it anytime within the standard one-year warranty period. When you finance your maintenance expenses, you can know and plan for a fixed cost upfront. Check with your local Vermeer dealer for specific model availability.
Specs
| GENERAL DIMENSIONS AND WEIGHTS | |
| Length | 147 in |
| Width | 35 in |
| Height | 80 in |
| Overall Width Transport (without duals) | 35 in |
| Overall Width Transport (with duals) | 56 in |
| Weight - Engine Option One | 4460 lbs |
| Sound Power | 110 dB(A) |
| ENGINE - OPTION ONE | |
| Make and Model | Deutz TD2.9L Tier Four Final |
| Number of Cylinders | 4 |
| Gross Horsepower (Maximum) | 74 hp |
| Torque (Max) | 192 ft-lb |
| Fuel Tank Capacity | 13.5 gal |
| Max Fuel Consumption | 3.9 gph |
| Fuel Type | Diesel |
| Air Cleaner | Two-stage dry type with maintenance-free precleaner, restriction indicator, evacuator valve and safety element |
| Oil Filter | Spin on |
| Recommended Oil | 15W40 |
| Oil Volume with Filter | 6.8 qt |
| Maximum Angle of Continuous Operation | 20 deg |
| Cooling Medium | Water / anti-freeze |
| Coolant Capacity (Engine and Radiator) | 3.9 gal |
| Alternator | 95 Amp |
| Fan | Remote variable speed suction |
| Clutch Type | Hydrostatic Transmission |
| CUTTERWHEEL SYSTEM | |
| Cutterwheel Diameter without Teeth | 23 in |
| Cutterwheel Thickness | 1.1 in |
| Cutterwheel Speed | 930 rpm |
| Cutterwheel Straight Line Dimension | 72 in |
| Cutterwheel Cut Above Ground | 31 in |
| Cutterwheel Cut Below Ground | 25 in |
| Tooth Description | Yellow Jacket Cutting System |
| Number of Teeth | 26 |
| Number of Indexes | 2 per tooth |
| Number of Pockets | 26 |
| Reversible Pockets | Yes - Standard |
| Cutterwheel Guard | Standard |
| Chip Containment | 28.2 cu ft |
| CUTTERWHEEL DRIVE COMPONENTS | |
| Lower Gearbox | 90 Degree |
| Oil Type - Lower Gearbox | Syn 75W90 |
| Oil Capacity - Lower Gearbox | 2.7 qt |
| Driveshaft | Standard |
| Driveshaft - U Joints | 2 Standard w/ double lip seals |
| HYDRAULIC SYSTEM | |
| Tank capacity | 18.4 gal |
| Recommended Oil Type | Vermeer HyPower 68 |
| System Type | 2 closed loops and 2 open loop |
| Filtration Method | Suction strainers and 3 micron return filter |
| Pump Flow at Maximum RPM | 15.8 gpm |
| System relief pressure | 3000 psi |
| Directional Control | Electric over hydraulic |
| Oil Cooler | Standard |
| ELECTRICAL SYSTEM | |
| System Voltage | 12V |
| Battery | 950 CCA |
| Standard Gauges | Hour meter, fuel gauge, tachometer |
| Warning Lights | Low oil pressure and high engine temperature |
| Switches | Cutterwheel drive engagement; AutoSweep adjustment, differential lock, Control panel selector (swingout or auxiliary), two-speed ground drive, blade, steering, boom controls and creep switches plus propel system joystick. |
| Controller | Vermeer ACS |
| Shutdown System | High coolant or hyd oil temp, low oil pressure |
| Radio Remote Control | Functions include: propel forward/reverse; boom up/down, boom left/right, steering left/right, blade up/down (optional), AutoSweep settings, travel speed high/low, differential lock, engine throttle |
| CHASSIS | |
| Frame Description | Swing out control station with 3 available positions plus auxiliary control station |
| Control Station Description | Abrasion resistant coated polycarbonate, 3/16 inch thick |
| Operator Vision Shield Description | None |
| Steerable Axle Type | Hydraulic, oscillating |
| Tires - Option One | Front: 20x8.00-10 |
| Wheels - Option One | Front: 10 inch x 6 inch rim |
| Axle/Suspension | Rigid at dual drive wheels; oscillating front steerable axle |
| Tires - Standard | Rear: Duals, 23x8.5-14 |
| Wheels - Standard | Rear: 14 inch x 6 inch rim |
| Brake Type | Spring applied, hydraulic release at planetary drives |
| GROUND DRIVE | |
| Low Speed Travel | 60 ft/min |
| High Speed Travel | 130 ft/min |
| OPTION ONE | |
| Chip Blade Dimension | Standard feature, 34 inches wide, 13.75 inches tall |
| Blade Travel Above Ground | 14 in |
| REMOTE CONTROL OPTION | |
| Radio Remote Control | Optional |
| Remote Functions | Engine start/stop, throttle, cutter wheel engage, swing, raise/lower |
| Remote Display | LED |
| Remote Range | 300' |
| OTHER OPTIONS | |
| Special Paint | Optional |
| Extended Warranty | 2 year/2000 hour or 3 year/3000 hour |
| Preventive Maintenance | Optional |
