Features
EASIER START-UP
Starts easier with the electronic fuel injected 26.5 hp (19.8 kW) EFI Kohler engine.
SELECTABLE TWO-SPEED GROUND DRIVE
Move easily between stumps with the selectable two-speed ground drive.
CONVENIENT BELT SERVICING
All of the belts are found on one side of the machine for convenient belt servicing.
EXTENDED WARRANTY
Protect your stump cutter investment with a 2-year/2000 hour or 3-year/3000 hour extended warranty
Specs
| GENERAL DIMENSIONS AND WEIGHTS | |
| Length | 110 in |
| Width | 49.8 in |
| Height | 52 in |
| Overall Width Transport (without duals) | 35 in |
| Overall Width Transport (with duals) | 49.8 in |
| Overall Height Transport | 52 in |
| Weight - Engine Option One | 1285 lbs |
| Sound Power | 105.4 |
| ENGINE - OPTION ONE | |
| Make and Model | Kohler Command Pro EFI |
| Number of Cylinders | 2 |
| Gross Horsepower (Maximum) | 26.5 hp |
| Torque (Max) | 44.3 ft-lb |
| Fuel Tank Capacity | 6 gal |
| Max Fuel Consumption | 2.7 gph |
| Fuel Type | Gas |
| Air Cleaner | Dry-type safety element and restriction indicator |
| Oil Filter | Spin-on |
| Recommended Oil | 10W30 Kohler |
| Oil Volume with Filter | 2 qt |
| Cooling Medium | Air |
| Alternator | 20 amp |
| Clutch Type | Electric clutch with brake |
| CUTTERWHEEL SYSTEM | |
| Cutterwheel Diameter without Teeth | 17 in |
| Cutterwheel Thickness | .5 in |
| Cutterwheel Speed | 1400 rpm |
| Cutterwheel Straight Line Dimension | 47 in |
| Cutterwheel Cut Above Ground | 24 in |
| Cutterwheel Cut Below Ground | 15 in |
| Tooth Description | Yellow Jacket cutter system |
| Number of Teeth | 16 |
| Number of Indexes | 2 |
| Number of Pockets | 16 |
| Reversible Pockets | 16 |
| Cutterwheel Guard | Standard |
| Chip Containment | 7.7 cu ft |
| CUTTERWHEEL DRIVE COMPONENTS | |
| Belt Type | V-Belt |
| Number of Primary Belts | 2 individual (matched pair) |
| Jackshaft Dimension | 1.3 |
| Jackshaft Bearing Type | Sealed ball |
| Bearing Dimensions | 1.3 bore |
| Number of Secondary Belts | 6 Banded |
| Cutterwheel Shaft | 1.8" (4.8 cm) |
| Bearing Dimensions - Secondary Belt | 1.8" (4.8 cm) double spherical roller pillow block |
| HYDRAULIC SYSTEM | |
| Tank capacity | 4 gal |
| Recommended Oil Type | Vermeer HyPower 68 |
| System Type | Open-loop series system |
| Filtration Method | Pump suction strainer (100 mesh) and 6 micron return filter |
| Pump Flow at Maximum RPM | 3.7 gpm |
| System relief pressure | 2030 psi |
| Flow ControlAuto | Sweep (option) or 2 speed ground drive |
| Directional Control | Manual hydraulic valve |
| ELECTRICAL SYSTEM | |
| System Voltage | 12 V |
| Battery | 400 CCA |
| Standard Gauges | Hourmeter |
| Warning Lights | Oil pressure, engine fault, operator presence status, clutch engage/disengagement status |
| Switches | Two-speed ground drive, clutch engage/disengage, operator presence handles |
| Controller | Vermeer ACS |
| Shutdown System | Oil pressure shutdown |
| CHASSIS | |
| Frame Description | Welded tube and plate steel |
| Control Station Description | Fixed side locations |
| Toolbox Description | Standard |
| Hitch Type | Adapter for TLR25 trailer |
| Steerable Axle Type | Manual single wheel or dual hydraulic steering axle |
| Tires - Option One | 5.7" x 8" (14.5 x 20.3 cm) with rear wheels - duals standard |
| Fender Description | Yes |
| Axle/Suspension | Rigid/Fixed |
| GROUND DRIVE | |
| Low Speed Travel | 66 ft/min |
| High Speed Travel | 133 ft/min |
