Features
Tractor key features include:
A four-post cab with ergonomically-positioned controls for maximum ease of operation and a transparent roof hatch providing extra visibility for front loader operations. The low-profile roof allows easier access to low-ceiling barns and sheds. The X6 tractor can be optionally equipped with a satellitebased guidance system and an ISOBUS terminal to maximize productivity and profitability.
New Deutz AG 3.6L engines with power ratings of up to 126 hp. These engines meet the Stage4/Tier4 Final emissions regulations using a selective catalytic reduction system (SCR) and a diesel oxidation catalyst (DOC).
DELUXE SLIM CAB: ALL-ROUND VISIBILITY AND TOTAL COMFORT
Deutz Tier 4 Final engine
The three models of the X6 Series are powered by advanced Deutz AG 3.6L four-cylinder turbo engines with multivalve technology, intercooler and common rail injection system. These innovative engines meet the Stage 4/Tier 4 Final emissions regulations using a selective catalytic reduction system (SCR) combined with a diesel oxidation catalyst (DOC).
Transmission configurable to your specific needs
The X6 standard tractors come in a vareity of transmission options to fit any need. Standard configuration includes power shuttle with four synchronized gears and three ranges providing 12 forward and 12 reverse speeds.
A 3-speed powershift option offers HML for each gear
allowing for 36 forward speeds.
For even more customization, a third transmission option with 3-speed power shift and creeper multiplies the 12 speeds of the standard transmission providing 48 forward and 16 reverse speeds for maximum efficiency in the field and on the road. Creeper gear allows for speeds as low as 0.19mph (0.31kph)
HIGHLIGHTS
- Manufactured, Designed, and Engineered by McCormick.
- 3.6L DEUTZ Engine
- Versatile Transmission capable of up to 48 speeds
- Hydraulic Power Shuttle with shuttle modulation control
- Push-Button 4WD Front Axle
- Heavy Lifting 3-Point Hitch
- Large 4-Post Cab with completely flat Foot Deck
- Open Center Hydraulic System
- 24.3gpm (92 lpm) Superior Hydraulic System
- Instructor’s Seat standard
- 25 mph (40 kph) Transport Speed
- Fully locking front and rear differentials
- Digital Front Dash Display
- 540 and 1000 speed PTO standard equipment
Specs
| Tractor Model | X6.45 |
| Engine | |
| Max Engine HP @ 2000 RPM HP (kW) | 119 (88) |
| Max PTO HP @ 2000 RPM HP (kW) | 95 (71) |
| Max. Engine Torque @ 1500 RPM lb ft (Nm) | 351 (476) |
| Engine Type | DEUTZ® liquid cooled diesel engine; Tier 4 using advanced Selective Catalytic Reduction (SCR) technology |
| Engine Size | 3.6 Liter, 4-cylinder |
| Fuel / DEF Capacity gal (liter) | 39 (150) / 5 (20) |
| Drive Train | |
| Standard Transmission | 12 x 12 speeds; hydraulic power shuttle |
| Optional Transmission (1) | 36 x 12 speeds; hydraulic power shuttle, 3-speed power-shift |
| Optional Transmission (2) | 48 x 16 speeds; hydraulic power shuttle, 3-speed power-shift, creeper gear |
| Brakes | Heavy duty wet multi-disc brakes |
| Differential Lock | Limited slip |
| 4wd Front Axle | Electro-hydraulic engagement with integrated front axle brakes |
| Hydraulics, 3-point Hitch, PTO | |
| Hydraulic System gpm (lpm) | Open center system; 16.4 (62) dedicated implement pump + 7.9 (30) dedicated steering pump |
| Rear Remote Valves | 3 Valves |
| Standard Rear 3-point Hitch Type | Category 2 with telescopic ball ends; electronic lift control |
| Optional Rear 3-point Hitch Type | Category 2 with quick attach hooks; electronic lift control |
| Rear 3-point Lift Capacity lb (kg) | 13,227 (6,000) standard |
| Rear PTO | 2 Speeds (540/1000 rpm) standardl; Optional 4 speeds (540/540E/1000/1000E); Groundspeed PTO optional |
| Operator's Area | |
| Cab | Deluxe 4 post cab, flat foot deck, radio system, silent-block suspension, instructor's seat |
| Seat and Front Dash | Deluxe air suspended seat; tilt and telescopic steering wheel |
| Wheelbase in (mm) | 95 (2,420) |
| Height Over Cab in (mm) | 104 (2,650) |
| Base Weight without ballast lb (kg) | 10,361 (4,700) |
